Tower Crane Specifications
The figures below describe typical industry specifications for this class of equipment rather than a single fixed model. Use them to scope a requirement, then confirm exact figures against the supplied unit before purchase.
| Specification | Typical value |
|---|---|
| Tip capacity | 1.5–12 t at maximum jib |
| Maximum capacity | 6–20 t close in |
| Jib length | 40–70 m typical |
| Hook height | 30–80 m free-standing, more when tied |
| Type | Flat-top or hammerhead, saddle-jib |
| Foundation | Cast-in anchors on a designed concrete base, or ballast chassis |
| Power | 400 V 3-phase 50 Hz, 30–80 kW |
| Wind limit | Out of service weathervaning; in-service typically 12–14 m/s |
| Erection | Mobile crane assist plus manufacturer climbing procedure |
What a Tower Crane Is Used For
- Building and civil construction
- Gold-plant steel and tank erection
- Precast and formwork handling
- Mine infrastructure and camp construction
- Port and industrial yard lifting
Maintenance Schedule
Most premature failures in this equipment class trace back to a missed routine check rather than a design fault. The intervals below are a practical starting schedule; adjust them to your duty cycle and the manufacturer manual.
| Interval | Task |
|---|---|
| Daily | Function test of hoist, trolley, slew and all limit switches; inspect wire rope and hook latch. |
| Weekly | Tower-bolt torque sample; inspect climbing frame and ties; check weathervane function. |
| Monthly | Full rope inspection to ISO 4309; brake air-gap; slew-bearing grease. |
| Quarterly | Structural inspection of jib and tower; foundation settlement check. |
| Annually | Thorough examination by a competent person; load test after any climb or modification. |
Frequently Asked Questions
How is tower-crane capacity quoted?
As a load chart: maximum lift close to the tower, falling as radius increases. Tip capacity at maximum jib is the number that actually limits most pours and steel lifts. A “12-tonne crane” that is 12 t at 15 m and 2 t at 60 m will not place a tank at the far corner of the pad. Size on the heaviest load at the greatest radius, not on the headline tonne rating.
Do I need a permit to erect a tower crane in Tanzania?
Erection and operation fall under occupational safety regulation and usually require a designed foundation, a competent-person erection plan and, in urban areas, additional local-authority approvals for oversail. Confirm OSHA Tanzania and municipal requirements before mobilising. Oversail of a public road or neighbouring plot is a legal issue, not just a site convenience.
When must a tower crane be climbed or tied?
When free-standing height exceeds the manufacturer’s chart for the in-service wind and the foundation used. Ties to the structure restore capacity as the building rises. Climbing or tying without following the manufacturer procedure is a common and serious failure mode.
